The high end full reflex wing to complete our paramotor wing range- this is the FORCE

FORCE was conceived as a direct result of pilot demand and with the added value of classic APCO virtues has exeeded all expectations. The result was the Perfect Match for your paramotor , with Spotless launch / Flare, sweet handling and light brake pressure.

FORCE designed as a high performance, maximum speed range glider, capable of competing with latest generation of reflex wings. The design brief for FORCE is based on the concept of combining all the best aspects of reflex wings with performance, handling and launch characteristics of APCO wings - perfectly blended into a well built, robust chute, made to last.

We again turned to use of SRS® (automatic stall recovery system - Pat. Pend.) to allow for comfortable take-off and landing speed. HIT® valves were incorporated to ensure maximum stability and internal wing pressure at any angle of attack. Built in FLEXON® to replace Mylar for long term consistent performance and lighter weight.

We are proud to be the first and original inventors of all the above, unique features - today gradually becoming an integral part of other brands design too.

Available in 3 sizes - FORCE S, M and L - covering weight range from 75kg.-185kg.

DESIGN FEATURES

• HIT valve® equipped on L/E for rock solid stability find out more »
• SRS® - APCO exclusive Stall Recovery System for built-in passive safety more »
• Flexon® battens system for ultimate durability - pioneered by APCO more »
• Replaceable trim webbing and camet buckle trim webbing and camet buckle for long-lasting trouble-free service more »
• Tip steering toggle location option for some pilots using frame with very high attachment points, additional set of lower connection points for tip steering toggles more »
• Easy launch and handling SRS aided
• Tip steering for high speed operation
• Minimal drag, integrated APCO exclusive hook-in point for unprecidented drag reduction
• Advance diagonal rib structure
• All metal parts Stainless Steel or Aluminium
• Split A risers with built-in safe, huge speed range
• APCO legendary standard double coated siliconised cloth - built to last
• Butt Holes
• Heavy-duty Superaramide® lines
• Swivels on brake handles
• Integral, built-in, Neodymium brake magnets
• Extended speed range: 23 to 67+ km/h
• Easy inflation, launch and landing
• Universal riser + accelerator and trimmers to fit any paramotor frame
• New color design - fresh and attractive

TECHNICAL DATA

	Small	Medium	Large
Product Code	31100	31200	31300
Cells	50	52	54
Area [m2]	25.48	27	28.52
Area (projected) [m2]	22.46	23.8	25.14
Span(incl. Stabiliser) [m]	11.88	12.48	13.08
Span (projected) [m]	9.91	10.41	10.91
Aspect Ratio	5.54	5.76	6.0
Aspect Ratio (projected)	4.37	4.55	4.73
Pilot Weight (all up) free flight[kg]	70-100	85-120	110-140
Pilot Weight (all up + paramotor unit) [kg]	75-140*	100-165*	125-185*
Canopy Weight [kg]	6.5	6.9	7.3
Root Cord m	2.56	2.56	2.56
Tip Chord [m]	0.43	0.43	0.43
Length of Lines on B [m]	7.08	7.5	7.9
Total Length of Lines [m]	389	412	435

* Higher wing loading advised when flying trike.

CERTIFICATION

Size	Certification Type
Force S	EN. C, additional DGAC
Force M	EN. C, additional DGAC
Force L	EN Test based Manufacturers test, additional DGAC

The FORCE has been thoroughly tested by us, here in our facility, and we have complete confidence in the wing.

PERFORMANCE

V-min [km/h]	23
V-trim [km/h]	38-41
V-trim off [km/h]	52-54
V-max [km/h]	67+
Min Sink [m/s] at optimal wing loading	less than 1.2 m/sec

COLOR OPTIONS

CONSTRUCTION AND MATERIALS

The glider is made from tear resistant Ripstop Nylon cloth, which is P.U. coated to zero porosity and then siliconized to give the fabric high resistance to the elements. Different cloth is used for the top, bottom and ribs due to their different functions. The lines are made of superaramid covered with a polyester sheath for protection against UV, wear and abrasion. The bottom section of the brake lines is made of polyester because of its better mechanical properties. The karabiners that attach the lines to the risers are made of stainless steel.

Fabric
Sail Cloth	42 g/m2 "Zero Porosity" Ripstop Nylon
L/E Reinforcement	FLEXON® batten system
Warranty	3 years / 250 Hours

	Material	Diameter [mm]	Strength [kg]
Top	Dyneema	1.0	90
Mid/Stabilo	Superaramide	1.2	120
Bottom (A3/A5/B3/B5)	Superaramide	1.8	230
Bottom (A1/B1)	Superaramide	1.9	320
Bottom (C/D)	Superaramide	1.5	150
Brakes Cascade/ St. Top	Dyneema	1.1	95
Steering Line	Polyester	2.0	85

Optional, FORCE can be supplied in light clinch bag (instead of paragliding carry bag) (upon request Free of Charge)

Optional, FORCE can be supplied with Wonder Bar (upon request - modest fee)
Former standard speed bar / stirrup discontinued.

OPTIONS AND ACCESSORIES
